CCTV LENS
CCTV Lens having :
Manual iris fixed lens
CE:RoHs
CCTV manual iris fixed lens ,50mm 1" CS F1.8
Model no. |
Vision-50 | ||||
| Focal length | 50mm | ||||
| Max. iris | 1:1.8-360 | ||||
| iris | manual | ||||
| Function | focus | manual | |||
| megapixel | 10mp | ||||
| distrotion | q<1% | ||||
| Focus range | ∞-300mm | ||||
| Format size | 1” | ||||
| Lens | 4group 6pcs | ||||
| dimension | 10mm | ||||
| mount | C | ||||
| View angle | 32º | dimension (L X W) | 53*53mm | ||
| size | 46*0.5mm | ||||
| temperature | -10℃ -- +50℃ | ||||
Another Model Specification for 2/3"Sensor
- Focal length: 50mm
- Format: 2/3"
- Aperture: F1.4
- Horizontal: 9.8 degree
- Min focusing range: Approx. 0.3cm
- Max. Focusing range: Infinity
- Focus operation: Manual
- Aperture operation: Manual
- Flange distance: 17.0mm
- Mount: C-Mount
- Suitable for MILCs (C-NEX adapter or C-M4/3 adapter ring needed)
- Package includes:
- 1 x Lens
- 1 x Macro ring
- 1 x Front lens cap
- 1 x Rear lens cap
